EQUIPMENT: Vastex FlashCures, Exposure Units, Drying Cabinets and Racks

This basic economy Flash Unit has adjustable Heat Control of 18" x 18" 1750W high density IR heater and a 3 year warranty covering the heater panel.  Available in 120 or 240 Volt, 15-18 Amp.    Convenient heavy duty side handles and low profile 2 3/4" head height are standard features    Adjustable height stand with vented heat shield on panel included.  Optional Rotary Table with vented pallets is also shown.

ROTARY TABLE FEATURE VIDEO

This premium Flash Unit had adjustable heat control of 18" x 18" (2000W) or 18" x 24" (3500W) high density IR heater and a 10 Year heater warranty.     Available in 120V or 240V for 18x18, 240V only for 18x24, 17-20 Amp.    Convenient heavy duty side handles and low profile 2 3/4" head height are standard features Adjustable height stand with vented heat shield on panel included.   This unit also has user friendly diagnostic pilot lights.    Automated servo option is also shown.

This state-of-art flash unit has an adjustable forced air system that protects delicate textiles, speeds the evaporative drying of water based inks, and cools the enclosure for operator safety.     It combines infrared heating with forced air to heat the ink while cooling the garment.    With water-based inks the flow of forced air across the infrared-heated ink accelerates evaporation, significantly reducing the time and energy needed to flash-dry each garment.  Rotary pallet option is also shown.

This entry level Screen Exposure system handles up to a 21" x 24" O.D. frame size.     Four 24" Blacklight 20 watt UV bulbs are standard on 3-1/2" centers, driven by electronic ballasts.    E1000 Model has a heavy duty vacuum frame with bearing lid locks for intimate exposure contact; E100 Model uses weighted compression for film positive contact.  A  precision timer controls lights (and vacuum on E1000 Model).   VRS Pin Registration compatible.  Optional upgrade to High-output U.V. 40 Watt bulbs for both models, and vacuum frame retrofit for E-100 is available.

Fast power vacuum hold down draws through the high-impact tempered glass that virtually eliminates breakage.    Two models are available; 23"x31" Max O.D. Frame size features six 28" High Output U.V. 40 Watt bulbs on 3-1/2" centers, and the 47"x31" Max O.D. Frame size uses twelve.    Both sizes are available in either 120V / 60 HZ or 240V / 50/60 HZ.  A precision digital timer controls lights and vacuum.     Both models have heavy duty construction with bearing lid locks.    VRS Pin Registration compatible

150 SERIES: 1200 watt instant start lamp.   20 Channel Scroll Set Light Integrator featuring Auto-OptimizeTM Technology.   Specially designed blanket for intimate contact with no air strings.   Vacuum gauge.   Maximum screen size: 31 x 41 inches (O.D.) Electrical: 120v, 60hz, 15a.   Touch activated, user friendly keypad with an LED digital display.   Load the frame, press START and walk away.   Fully automatic operation completes the entire process.   Overall dimensions: 44"D x 51"W

This high-strength Utility Cart can be used for mounting Table-top Vastex Printers, or for a variety of other uses.  Holds up to 23” x 31” Screens.   Locking casters for easy mobility.  Configure the adjustable shelves how you want them.  Optional side shelves for storing squeegees, ink scoops & small tools.  Optional door kit turns cart into a light-tight storage unit for coated screens. Cart dimensions: 39” x 26” x 32”.

This rolling screen rack holds up to 24 screens in either 20” x 24” or 23” x 31” frame sizes.  Shelves are angled for frame edge contact only. Assembled size:  24.5”W x 29”D x 71”H.  1 year warranty on manufacturer's defects.  This rack ships UPS in two boxes, 36” x 28” x 8” 50 lbs x 2 and easily assembles in under one hour.

This professional screen drying cabinet holds screens up to 25" x 36" Max O.D.  Industrial stainless steel finned heater Blower provides 150 c.f.m.  filtered air. Pressurized air flow system can dry screens in as little as 20 minutes.  Features breaker/switch and pilot light for easy control. Screens sit horizontal on removable shelves. Shelves are angled for frame edge contact only. Sealed door with mechanical latch handles. Optional casters. 3 year warranty.

This high-capacity version of the Dri-Vault 10 holds 20 screens up to 25" x 36" or 10 screens up to 36" x 51" Max O.D. Industrial stainless steel finned heater.  Pressurized cabin with positive air flow keeps out contaminants even if an air leak occurs. Screens sit horizontal on removable shelves (angled to provide edge contact only).  Dries fully loaded cabinet in as quickly as 40 minutes.  Light tight heavy duty double wall construction and easy to replace filtered air intake.  Optional digital temperature control.

This high-capacity version of the Dri-Vault 10 holds 24 screens up to 25" x 36" Max O.D. Features digital temperature controller Industrial-grade stainless steel finned heater. Quick, consistent, and clean drying. Air only or heat and air optional settings are standard. Heavy-duty double wall Adjustable sealed door with mechanical latch handles. Heavy-duty locking casters are standard. 3 year warranty.
